What you'll learn
- Understand the internal structure and pinout of a 7-segment LED display.
- Implement a truth table in code to control multiple outputs simultaneously.
- Distinguish between Common Cathode (CC) and Common Anode (CA) configurations.
- Apply current-limiting techniques for multiple LED segments.
What's in the kit
- Arduino UNO
- 1-Digit 7-Segment Display (Common Cathode)
- 220Ω Resistor×8
- Breadboard
- Jumper Wires (M-M)×10
Protocol: digital
